Heavy storage shelves play a very important role in storage. The application field of heavy pallet shelf is obvious to all, and it plays a very important role in real life. It can be widely used in large warehouses, which generally use pallets to access various goods. So how do we buy heavy pallet shelves? Next, hegerls will take you to analyze how to buy heavy pallet shelves?
Heavy pallet rack structure
Pallet shelves are used to store unitized pallet goods, and are equipped with laneway stackers and other storage and transportation machinery for operation. The high-rise shelves are mostly of integral structure, generally made of welded shelf pieces (with trays) of profile steel, which are connected by horizontal and vertical tie rods, beams and other components. The side clearance shall consider the parking accuracy of the goods at the original position, the parking accuracy of the stacker, and the installation accuracy of the stacker and shelf; The width of the cargo support must be greater than the side clearance, so as to prevent the cargo side from being unsupported. It is easy to disassemble and move. It can adjust the position of the beam according to the height of the goods. It is also called adjustable pallet shelf.
Working principle of heavy pallet rack
Also commonly known as beam type shelf, or cargo space type shelf, it is usually a heavy-duty shelf, which is most common in various domestic storage shelf systems. First of all, the unitization of containerization shall be carried out, that is, the packing of goods and their weight and other characteristics shall be assembled to determine the type, specification, size of pallets, as well as the loading capacity and stacking height of single pallet (the weight of single pallet is generally less than 2000kg), and then the span, depth and layer spacing of unit shelves shall be determined. The height of shelves shall be determined according to the effective height of the lower edge of the warehouse roof truss and the maximum fork height of the forklift. The unit shelf span is generally within 4m, the depth is within 1.5m, the shelf height of low and high-level warehouses is generally within 12M, and the shelf height of super high-level warehouses is generally within 30m (these warehouses are basically automated warehouses, and the total shelf height is composed of several sections of columns within 12m). In such warehouses, most of the low and high-level warehouses use forward moving battery forklifts, balance weight battery forklifts and three-way forklifts for access. When the shelves are low, electric stackers can also be used. The super high-level warehouses use stackers for access. This kind of shelf system has high space utilization, flexible and convenient access, and can basically meet the requirements of a modern logistics system with computer management or control. It is widely used in manufacturing, third-party logistics, distribution centers and other fields. It is applicable to both multi variety and small batch goods and small variety and large batch goods. Such shelves are most widely used in high-level warehouses and super high-level warehouses (such shelves are mostly used in automated warehouses). Pallet shelves have high utilization rate, flexible and convenient access. Assisted by computer management or control, pallet shelves can basically meet the requirements of modern logistics systems.
Characteristics of heavy pallet shelf
The heavy pallet shelf is formed by rolling high-quality cold-rolled steel plate. The column can be as high as 10 meters without joints in the middle. The cross beam is made of high-quality square steel, which has large bearing capacity and is not easy to deform. The hanging parts between the cross beam and the column are inserted by cylindrical protrusions, which are reliable in connection and easy to disassemble and assemble. Locking nails are used to prevent the cross beam from being lifted by the forklift when it is working; The surfaces of all shelves are treated by pickling, phosphating, electrostatic spraying and other processes to prevent corrosion and rust, and have a beautiful appearance. Meet the storage and centralized management needs of large quantities of goods and a wide variety of products, and cooperate with mechanical handling tools to achieve orderly storage and handling; The goods stored in the hegris heavy pallet shelf do not squeeze each other, and the material loss is small, which can fully ensure the function of the material itself and reduce the possible loss of the goods in the storage process. This kind of heavy pallet rack is used in processing industry, third-party storage, logistics distribution center and other industries, which is not only suitable for mass production of multiple types of articles, but also suitable for mass production of fewer types of articles. This kind of storage rack is used most in the upper warehouse and super upper warehouse.
So how to buy heavy pallet shelves?
1) Plant structure, available height, beam column position, maximum bearing capacity of the floor, fire prevention facilities: when purchasing heavy pallet shelves, the effective height of the warehouse space must be considered to determine the shelf height; The position of beams and columns will affect the configuration of shelves; The strength and flatness of the floor are related to the design and installation of shelves; Installation position of fire prevention facilities and lighting facilities; Select shelf specifications according to the appearance, size and actual condition of the stored goods.
2) Weight of goods: the weight of stored goods directly affects the strength of heavy pallet shelves; In which unit to store, pallets, storage cages or single items have different shelves.
3) The growth needs of the company in the next two years must be considered: the total number of cargo spaces is estimated. This information can be obtained from the analysis of the storage system, or the professional heavy pallet shelf factory can give professional advice before design.
Post time: Sep-06-2022
